RV-H21VIP

RV-H21VIP

                14MILX18PCS IR LED

0.00
0.00

Product Description

                14MILX18PCS IR LED





Camera

RV-H21VIP200H

Image Sensor

IMX307

Main processor

HI3516EV200

Resolution

2.0MP

Effective Pixels

1920*1080

Compression

H.265+/H.265/H.264/MJPEG

TV System

PAL/NTSC

Electronic Shutter Time

Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec

Min Illumination

0.001Lux

S/N Ratio

≥52dB

Scanning System

Progressive

Video Output

Network

Night Vision
Infrared LED

14MIL x18PCS

Infrared Distance

20M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

LENS
Length

2.8-12mm

Pixels

3MP

Network
Ethernet

RJ-45 (10/100Base-T)

Protocol

TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP

ONVIF

Support ONVIF 2.4

P2P

optional

POE

Optional, Support IEEE 802.3af

Audio

optional

WIFI

N/A

Video Delay

0.3S (Within the Lan)

IE Brower

IE8-11, Google Chrome, Firefox, Safari, Mac Safari

Camera Features
Day/Night

Color/ B&W (IR-CUT )

Image Config

Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control)

BLC

Support

WDR

Support

Motion Detection

Support

Privacy  Masking

3 Rectangular Zone

Recording Mode

NVR/UCOption,VMS)/Web

Language

Chinese Simplified, Chinese Traditional, English,

Housing

Metal

IR Cut Filter

YES

Operation Temperature

-30 ~ +60 RH95% Max

Storage Temperature

-40 ~ +60 RH95% Max

Power Source

DC12V±10%, 600mA

Dimension

139 x 122(H) mm

Weight

                                                 1500g



 Camera

RV-H21VIP300

 Image Sensor

SC4236

 Main processor

HI3516EV200

 Resolution

3.0MP

 Effective Pixels

 2304*1296

 Compression

H.265+/H.265/H.264/MJPEG

 TV System

PAL/NTSC

 Electronic Shutter Time

Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec

 Min Illumination

0.001Lux

 S/N Ratio

≥52dB

 Scanning System

Progressive

 Video Output

Network

 Night Vision
 Infrared LED

14MIL x18PCS

 Infrared Distance

20M

 IR Status

Under 10 Lux By CDS

 IR Power On

CDS Auto Control

 LENS
 Length

2.8-12mm

 Pixels

4MP

 Network
 Ethernet

RJ-45 (10/100Base-T)

 Protocol

TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP

 ONVIF

Support ONVIF 2.4

 P2P

optional

 POE

Optional, Support IEEE 802.3af

 Audio

optional

 WIFI

N/A

 Video Delay

 0.3S (Within the Lan)

 IE Brower

IE8-11, Google Chrome, Firefox, Safari, Mac Safari

 Camera Features
 Day/Night

Color/ B&W (IR-CUT )

 Image Config

Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control)

 BLC

Support

 WDR

Support

 Motion Detection

Support

 Privacy  Masking

3 Rectangular Zone

 Recording Mode

NVR/UCOption,VMS)/Web

 Language

Chinese Simplified, Chinese Traditional, English,

 Housing

Metal

 IR Cut Filter

YES

 Operation Temperature

-30 ~ +60 RH95% Max

 Storage Temperature

-40 ~ +60 RH95% Max

 Power Source

DC12V±10%, 600mA

 Dimension

139 x 122(H) mm

 Weight

1500g


 Camera

RV-H21VIP500H

 Image Sensor

IMX335

 Main processor

HI3516EV300

 Resolution

5.0MP

 Effective Pixels

 2592*1944

 Compression

H.265+/H.265/H.264/MJPEG

 TV System

PAL/NTSC

 Electronic Shutter Time

Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec

 Min Illumination

0.001Lux

 S/N Ratio

≥52dB

 Scanning System

Progressive

 Video Output

Network

 Night Vision
 Infrared LED

14MIL x18PCS

 Infrared Distance

20M

 IR Status

Under 10 Lux By CDS

 IR Power On

CDS Auto Control

 LENS
 Length

2.8-12mm

 Pixels

6MP

 Network
 Ethernet

RJ-45 (10/100Base-T)

 Protocol

TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP

 ONVIF

Support ONVIF 2.4

 P2P

optional

 POE

Optional, Support IEEE 802.3af

 Audio

optional

 WIFI

N/A

 Video Delay

 0.3S (Within the Lan)

 IE Brower

IE8-11, Google Chrome, Firefox, Safari, Mac Safari

 Camera Features
 Day/Night

Color/ B&W (IR-CUT )

 Image Config

Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control)

 BLC

Support

 WDR

Support

 Motion Detection

Support

 Privacy  Masking

3 Rectangular Zone

 Recording Mode

NVR/UCOption,VMS)/Web

 Language

Chinese Simplified, Chinese Traditional, English,

 Housing

Metal

 IR Cut Filter

YES

 Operation Temperature

-30 ~ +60 RH95% Max

 Storage Temperature

-40 ~ +60 RH95% Max

 Power Source

DC12V±10%, 600mA

 Dimension

139 x 122(H) mm

 Weight

1500g
